The Sermoon S1 is a blue-laser handheld 3D scanner from Creality that blends multiple laser channels with infrared structured light. It offers a 5 mm to 4 m working range and an accuracy of 0.02 mm, delivering up to 90 FPS and 1,428,000 points per second. The system includes three laser modes, 34 cross-line lasers, and two NIR structured-light modes for marker-free scans. The workflow centers on CrealityScan with one-click processing, and compatible software supports industrial reverse engineering. More details await.
Overview of the Sermoon S1 and Its Core Specs
The Sermoon S1 from Creality is a blue-laser handheld 3D scanner designed for high-speed, precise profiling of objects and bodies. The device combines 1+7+34 laser channels within a 5mm–4m working range and 0.02mm accuracy, enabling fine detail capture and deep hole detection at 0.1mm.
It supports Windows and macOS, with 90 FPS performance and up to 1,428,000 points per second. Three laser modes plus two NIR structured-light modes offer flexible scanning. The system emphasizes hardware durability and consistent performance, while pricing tiers address varying user needs, from hobbyist to professional workflows, under CrealityScan integration.
Scanning Capabilities: Laser Modes, NIR Structured Light, and Speed
Scanning capabilities of the Sermoon S1 are defined by a combination of laser modes, NIR structured light, and high-speed data capture. The system uses three blue laser modes for targeted depth and narrow gaps, plus 34 cross-line lasers for rapid large-area coverage and ultra-fine 0.1mm lines for detail. Two NIR structured light modes enable marker-free scanning with diverse fields of view. Speed capabilities are supported by 90FPS scanning and up to 1,428,000 points per second, with parallel and single-line modes at 90fps and cross lines at 70fps. This arrangement yields consistent scanning speed across varied geometries and object sizes.
laser modes nir structured light speed capabilities scanning speed.
Software, Workflow, and Real-World Use Cases
Software workflows center on the CrealityScan app, which guides users from setup to post-processing with step-by-step tutorials and one-click processing. The workflow emphasizes reliable point-cloud editing, body/face modes, and full global marker scanning, enabling repeatable results across sessions. Interoperability remains a strength, with seamless integration to Geomagic Control X, Design X, and Verisurf Inspect for downstream quality control and reverse engineering tasks. Real-world use cases include industrial reverse engineering and 3D printing pipelines, though an unrelated topic occasionally appears in documentation, reminding users to verify measurements independently. Silent operation during scans contributes to unobtrusive on-site assessments and calibration.
Conclusion
The Sermoon S1 presents a versatile scanning platform that blends handheld flexibility with robust multimodal capture. Its laser configurations, infrared structured-light, and high frame rate enable a range of applications from large-scale scans to fine internal features, while modular options let users tailor the setup to their geometry. Software integration with CrealityScan and compatibility with industry tools support practical workflows for reverse engineering and QC. Overall, it offers dependable data quality and adaptable workflows for makers and professionals alike.
